Bootstrapping Flux with Terraform, the right way

A Terraform module that bootstraps Flux Operator without fighting Flux for resource ownership, keeps secrets out of state, runs in the same root module as the cluster, and handles platform prerequisites that Flux itself depends on.
By Matheus Pimenta |
Tags:

This post introduces a new Terraform module (fully compatible with OpenTofu) that bootstraps Flux Operator into a Kubernetes cluster and then steps aside, letting Flux do what Flux does best.

Here are some of the problems it sets out to fix.

Ownership handoff

Terraform is the natural place to install Flux right after a cluster comes up, since credentials are in scope and providers are wired. But once Flux is online, every object Terraform applied is now also an object Flux wants to reconcile. The traditional workarounds (the fluxcd/flux provider, or chained helm_release resources) keep Terraform on the hook for steady-state reconciliation forever.

This module takes a different approach. Terraform owns only the bootstrap mechanism: a namespace, temporary RBAC, and a Kubernetes Job that applies Flux Operator and the FluxInstance. The module implements a create-if-missing strategy. Flux adopts the resources and Terraform stops touching it. When inputs are unchanged, terraform plan shows zero diff.

Using one GitOps repository

The Terraform root module and the Flux manifests live side-by-side in the same repository, so the bootstrap inputs and the steady-state desired state are versioned together:

repo/
├── terraform/                             # Terraform root module
│   ├── main.tf
│   ├── providers.tf
│   └── variables.tf
└── clusters/
    └── staging/                           # reconciled by Flux via FluxInstance.spec.sync.path
        └── flux-system/
            ├── flux-instance.yaml         # applied by the bootstrap Job
            ├── flux-operator-values.yaml  # shared between Terraform and the Flux-managed HelmRelease
            ├── flux-operator.yaml         # ResourceSet wrapping the Flux Operator HelmRelease
            ├── runtime-info.yaml          # Git-managed fields of flux-runtime-info (optional)
            └── kustomization.yaml         # configMapGenerator for flux-operator-values

The Terraform module loads the same flux-instance.yaml that Flux will reconcile after bootstrap and provisions the Git pull secret it needs to keep syncing the repository:

module "flux_operator_bootstrap" {
  source   = "controlplaneio-fluxcd/flux-operator-bootstrap/kubernetes"
  revision = 1

  gitops_resources = {
    instance_yaml = file("${path.root}/../clusters/${var.cluster_name}/flux-system/flux-instance.yaml")
  }

  managed_resources = {
    secrets_yaml = <<-YAML
      apiVersion: v1
      kind: Secret
      metadata:
        name: flux-system
      type: Opaque
      stringData:
        username: git
        password: '${var.git_token}'
    YAML
  }
}

No secret material ever lands in the Terraform state file. The module marks managed_resources as sensitive and only persists a SHA-256 hash to detect changes, while still reconciling drift on every run with server-side apply - the same model as kustomize-controller. Pull values from Vault, AWS Secrets Manager, or any other store via data sources and compose them into secrets_yaml; the rendered YAML never appears in state.

No two-phase apply

The module does not require cluster connectivity at plan time. Because the configuration is static, it can live in the same Terraform root module that creates the cluster. Since the plan doesn’t need runtime information, the operator bootstrap can directly depends_on the cluster module instance:

module "cluster" { source = "..." }

provider "helm" {
  kubernetes = {
    host                   = module.cluster.endpoint
    cluster_ca_certificate = base64decode(module.cluster.ca_certificate)
    token                  = module.cluster.token
  }
}

module "flux_operator_bootstrap" {
  depends_on = [module.cluster]
  source     = "controlplaneio-fluxcd/flux-operator-bootstrap/kubernetes"
  revision   = 1
  # ...
}

Flux’s own dependencies: CNI and Storage

Some components have to exist before Flux can run (a self-managed CNI like Cilium is a good example). Without a CNI, pods lack network access, and this includes the Flux controllers themselves. The new Terraform module accepts an ordered list of prerequisite Helm charts and manifests, which are applied in sequence by the bootstrap Job before Flux Operator. For the CNI scenario, we let the Job run with host_network: true, since pod networking is unavailable until after the CNI comes up:

job = {
  host_network = true
}

gitops_resources = {
  instance_yaml = file("${path.root}/../clusters/${var.cluster_name}/flux-system/flux-instance.yaml")
  prerequisites = {
    charts = [
      { name = "cilium", repository = "quay.io/cilium/charts/cilium", namespace = "kube-system" },
    ]
  }
}

This extends to any component your Flux install depends on. The same mechanism can handle CSI drivers that the Flux controllers may need to mount before they can start. This lays the groundwork for an upcoming SPIFFE/SPIRE integration that we’ll have more to share about in the next few releases. Any of these components then become adopted by Flux for steady-state reconciliation, following the same handoff described above that’s used for the Flux Operator HelmRelease and FluxInstance.

This module bootstraps Flux Operator without fighting Flux for resource ownership. It keeps secrets out of the state file, runs in the same root module as the cluster itself, and bootstraps platform prerequisites like CNI and CSI that Flux itself depends on before handing management of those add-ons back to Flux.

Migrating
